RTL8762D Series

Introduction

RTL8762D supports Bluetooth 5.1, ultra low power consumption, with 90MHz high frequency ARM Cortex-M4F processor, high flash memory, flexible GPlO design. lt is widely used in smart home, Bluetooth Mesh, wearable devices, smart door locks and otherproducts. The Secure boot function of RTL8762D greatly enhances the security of the solution. Supports the UI interface of I8080 and QSPI, and provides professional UI SDK services.

DESCRIPTION

CHIP

Specifications

General Description
  • Supports Bluetooth 5.1 core specification
  • Supports LE 2Mbps
  • LE advertising Extensions
  • LE Long Range
  • High Duty Cycle Non-Connection Adv
  • Supports OTA (Over-The-Air)
  • Supports AoA/AoD
MCU Platform
  • ARM Cortex-M4F max frequency 90MHz
  • 192KB SRAM totally
  • Serial Flash Controller (1-bit&4-bits mode)with 16KB 4-way cache
  • Supports AES-128/192/256 encryption/decyption engine
  • MCM Flash512/1024KB (depends on detail part number)
  • Supports secure boot,  encryption code execution
Peripheral Interface
  • Flexible GPIO
  • Hardware Keyscan and Quad-decoder
  • Embedded IR Transceiver
  • Real-Time Counters (RTC)
  • SPI master/slave ×2, Timers ×8, I2C ×2, PWM ×8, UART ×2
  • 400ksps, 12bits, 8 channels AUXADC
  • I2S interface for external audio codec
  • I8080 interface for LCD
  • Internal 32K RCOSC to keep BLE link
  • Embedded PGA and audio ADC with 5-band EQ
RF Performance
  • Tx Power: 0/4/7.5 dBm adjustable (refer to datasheet for details)
  • Rx Sensitivity: -97dBm BLE
  • Fast AGC control to improve receiving dynamic range

RTL8762D Series

General Description
  • Supports Bluetooth 5.1 core specification
  • Supports LE 2Mbps
  • LE advertising Extensions
  • LE Long Range
  • High Duty Cycle Non-Connection Adv
  • Supports OTA (Over-The-Air)
  • Supports AoA/AoD
MCU Platform
  • ARM Cortex-M4F max frequency 90MHz
  • 192KB SRAM totally
  • Serial Flash Controller (1-bit&4-bits mode)with 16KB 4-way cache
  • Supports AES-128/192/256 encryption/decyption engine
  • MCM Flash512/1024KB (depends on detail part number)
  • Supports secure boot,  encryption code execution
Peripheral Interface
  • Flexible GPIO
  • Hardware Keyscan and Quad-decoder
  • Embedded IR Transceiver
  • Real-Time Counters (RTC)
  • SPI master/slave ×2, Timers ×8, I2C ×2, PWM ×8, UART ×2
  • 400ksps, 12bits, 8 channels AUXADC
  • I2S interface for external audio codec
  • I8080 interface for LCD
  • Internal 32K RCOSC to keep BLE link
  • Embedded PGA and audio ADC with 5-band EQ
RF Performance
  • Tx Power: 0/4/7.5 dBm adjustable (refer to datasheet for details)
  • Rx Sensitivity: -97dBm BLE
  • Fast AGC control to improve receiving dynamic range

Part Number Comparison

Part Number
RTL8762DGF
RTL8762DGF-VS
RTL8762DDF
RTL8762DKF
RTL8762DKF-VS
RTL8762DT

MCU

CM4F@90MHz

CM4F@90MHz

CM4F@60MHz

CM4F@90MHz

CM4F@90MHz

CM4F@90MHz

Flash

512KB

1024KB

512KB

512KB

1024KB

External

RAM

192KB

192KB

192KB

192KB

192KB

192KB

Protocol

BLE 5.1

BLE 5.1

BLE 5.1

BLE 5.1

BLE 5.1

BLE 5.1

TxPower (max dBm)

7.5dBm

7.5dBm

7.5dBm

7.5dBm

7.5dBm

7.5dBm

I8080

0

0

0

0

0

1

QSPI

0

0

0

0

0

1

Secutiry

Secure boot AES/TRNG

Secure Boot SHA-256/AES

Secure Boot SHA-256/AES

Secure Boot SHA-256/AES

Secure Boot SHA-256/AES

Secure Boot SHA-256/AES

AUX ADC

400ksps, 12bits 4 channels

400ksps, 12bits 4 channels

400ksps, 12bits 6 channels

400ksps, 12bits 8 channels

400ksps, 12bits 8 channels

400ksps, 12bits 8 channels

GPIO (max)

18

18

26

34

34

38

SPI

M×2, S×1

M×2, S×1

M×2, S×1

M×2, S×1

M×2, S×1

M×2, S×1

Package (mm)

QFN32, 5×5

QFN32, 5×5

QFN40, 5×5

QFN48, 6×6

QFN48, 6×6

QFN56, 7×7

Applications

Learn about the typical application cases that the RTL8762D series can be used to implement. Of course, there are more applications waiting for you to discover.

appli sce
Smart Lock

Bluetooth smart lock enable keyless access via smartphone or custom passwords, offering both convenience and security. Bluetooth technology ensures quick response, low power consumption, and easy installation. Realtek's Bluetooth chip series provides full support with stable connectivity and mature development tools, helping customers bring competitive products to market efficiently.

appli sce
Smart Charging Case

The Realtek smart charging case utilizes Bluetooth technology for seamless connection with headphones and smartphones. Equipped with Auracast™ technology, it revolutionizes the way users interact with audio devices, making it a critical node for audio information transmission. Additionally, the product supports various interfaces such as I2S, USB, ADC, SDIO, SPDIF, and QSPI, significantly enhancing versatility and providing robust support for a wide range of smart charging case products from entry-level to high-end.

appli sce
Smart HMI

The Realtek HMI system integrates multiple connection protocols such as Wi-Fi, Thread, Matter, and BLE, and is equipped with efficient UI development tools to provide customers with a one-stop solution from "underlying connection" to "top-level interaction". It adopts a dual RF scheme, supporting the 15.4 protocol and BLE Mesh to work collaboratively, reducing the loss rate of critical events in smart homes. The system also supports Ethernet and CAN interfaces, meeting the stable communication needs of industrial automation and vehicle data reading. Additionally, users can use the LVGL, Honey GUI engine, and RVD tools to quickly develop smooth touch interfaces.

appli sce
Smart Lock

Bluetooth smart lock enable keyless access via smartphone or custom passwords, offering both convenience and security. Bluetooth technology ensures quick response, low power consumption, and easy installation. Realtek's Bluetooth chip series provides full support with stable connectivity and mature development tools, helping customers bring competitive products to market efficiently.

appli sce
Smart Charging Case

The Realtek smart charging case utilizes Bluetooth technology for seamless connection with headphones and smartphones. Equipped with Auracast™ technology, it revolutionizes the way users interact with audio devices, making it a critical node for audio information transmission. Additionally, the product supports various interfaces such as I2S, USB, ADC, SDIO, SPDIF, and QSPI, significantly enhancing versatility and providing robust support for a wide range of smart charging case products from entry-level to high-end.

appli sce
Smart HMI

The Realtek HMI system integrates multiple connection protocols such as Wi-Fi, Thread, Matter, and BLE, and is equipped with efficient UI development tools to provide customers with a one-stop solution from "underlying connection" to "top-level interaction". It adopts a dual RF scheme, supporting the 15.4 protocol and BLE Mesh to work collaboratively, reducing the loss rate of critical events in smart homes. The system also supports Ethernet and CAN interfaces, meeting the stable communication needs of industrial automation and vehicle data reading. Additionally, users can use the LVGL, Honey GUI engine, and RVD tools to quickly develop smooth touch interfaces.

*Specific applications may can only be supported by certain chips
