Realtek's Dual-Mode BT SOC series is a single-chip solution that integrates RF, PMU, CODEC, USB, high-performance CPU, and DSP, while also providing a rich set of IO interfaces. It boasts powerful computational capabilities, supports multiple algorithms, and simultaneously supports dual-mode Bluetooth (classic Bluetooth and Bluetooth Low Energy) as well as BLE audio technology, providing users with stable and reliable wireless transmission. For applications that require high-speed data transmission and low-power, small data transmission, the SOC series offers flexibility and reliability.
The SOC series finds wide applications in various fields that require wireless connectivity, audio processing, and image display functions, such as open wireless earphones (OWS), stereo headphones, gaming headphones, speakers, wearable devices, charging cases with smart screens, and smart dashboards, among others. Realtek also meets the diverse needs of different customers by offering differentiated solutions in terms of package size, GPIO count, SDK tools, audio algorithms, image processing algorithms, power management, and amplifiers.
With its high integration, strong computational capabilities, stable and reliable wireless transmission, and flexibility, the SOC series provides users with high-performance solutions in various application domains.
Dual-Mode BT Selection Table
RTL8763E & RTL8773ESL | RTL8773E | RTL8773D | |
---|---|---|---|
BT version | BT 5.3 | BT 5.3 | BT 5.3 |
BLE audio | RTL8763EFL, RTL8763EAU, RTL8763EW-VP only | Yes | Yes |
PAwR | No | Yes | No |
Max Tx Power | 10dBm@BR | 13dBm@BR | 12.5dBm@BR |
Package (mm) | QFN50 4x6 QFN40 4x6 QFN68 7x7 BGA149 7x7 | QFN68 7x7 | BGA184 4.9x6 |
Security engine | TRNG Secure Boot(RSA-2048) SHA256 AES128/256 | TRNG Secure Boot(RSA-2048) SHA256 AES128/256 | TRNG Secure Boot(RSA-3072) SHA256 AES128 |
SM3 encryption | No | Yes | No |
MCU | Real-M300, (CM33 Like) 32-bit ARMv8M mainline processor@100MHz | Real-M300+FPU (CM33Like) 32-bit ARMv8M mainline processor@100MHz | ARM Cortex-M4F@160MHz |
DSP | Tensilica HiFi mini compatible@200MHz | Tensilica HiFi mini compatible@200MHz | Tensilica Hi-Fi mini@320MHz+Tensilica HiFi4@320MHz |
SRAM size | 532KB shared SRAM | 800KB shared SRAM | DSP+MCU total 3MB |
Flash size | MCM 4MB/External | External | MCM 8MB/16MB |
PSRAM size | 0/MCM 4MB (RTL8763EW-VP) | 0/MCM 4MB/ MCM 8MB | 0 |
Available GPIO Number | 9 / 12 / 38 / 80 | 38 | >60 |
I/O ADC | 4CH 12bits | 4CH 12bits | 8CH 12bits |
USB | USB2.0( RTL8763ESE, RTL8763EAU and RTL8763EW-VC only ) | No | USB2.0 |
I2S | x2 Formats : Left-Justified, PCM mode-A, PCM mode-B Application sampling rate : 48KHz Master and slave mode No master clock (MCLK) output | x2 Formats : Left-Justified, PCM mode-A, PCM mode-B Application sampling rate : 48KHz Master and slave mode No master clock (MCLK) output | x4 Formats :Left-justified, right-justified, PCM mode-A, PCM mode B Application sampling rate : up to 192KHz master clock (MCLK) |
I8080 | Yes (RTL8763EWE/RTL8763EW series) | Yes | No |
RAMLESS LCD | No | Yes | No |
Display Resolution (RGB565) | QSPI, 50MHz 454x454, 45fps | QSPI, 80MHz 500x500, 60fps | No |
RGB888 interface | No | Yes | No |
2.5D Engine | No | Yes | No |
IDU (Image processor unit) | No | Yes | No |
CAN Bus | No | Yes | No |
SPDIF | No | No | Yes |
A-MIC number | x3 | x2 | x4 |
D-MIC number | x4 | x4 | x6 |
Aux in | L and R 2 channels | L and R 2 channels | L and R 2 channels |
SPK/DAC | Class D x2 | DAC out x1 | class AB x2 + class D x2 |
ANC | FF + FB Hybrid | No | Adaptive ANC |
UART | x3 HW flow control max baud rate at 4MHz | x3 HW flow control max baud rate at 4MHz | x4 HW flow control max baud rate at 4MHz |
I2C | x3 master/Slave mode Max data rate at 400Kbps | x3 master/Slave mode Max data rate at 400Kbps | x3 master/Slave mode Max data rate at 400Kbps |
PWM | x8 | x12 | x16 |
Sleep LED | Yes | No | Yes |
SPI | x3 SPI0: Master + slave role SPI1: Master only SPI2 :Master only | x3 SPI0: Master + slave role SPI1: Master only SPI2 :Master only | x3 SPI0: Master + slave role SPI1: Master only SPI2 :Master only |
SDIO | x1 (RTL8763EWE/RTL8763EW series) | x1 | x1 |
SPIC | x2 (RTL8763EWM, RTL8763EWE series) x4 (RTL8763EW series) | x2 | x3 |
Operation voltage | 2.8V to 4.5V (VBAT) | 2.8V to 4.5V (VBAT) | 3V~5V (VBAT) |
