Introduction
The RTL8771H/G is a highly integrated single-chip Thread RCP solution featuring UART (RTL8771HTV or RTL8771GTV) / USB (RTL8771GUV) interfaces. It provides the Host with different Thread device capabilities, such as a Routing Node or OTBR (Open Thread Border Router), through UART or USB interfaces. Additionally, it can support Matter applications on this basis, enabling the creation of node-type Thread Matter devices or the construction of Matter gateways with OTBR functionality.
DESCRIPTION
CHIP
Highlights
With USB and UART, along with a mature SDK, it is very convenient to complete the porting to Android/Linux platforms.
Realtek can provide Host-side RCP as a gateway and offer corresponding Node-side device IC services for customers across the entire ecosystem.
Specifications
- RCP Radio Co-processor
- Thread RCP
- Supports Android/Linux Host
- Supports UART (RTL8761CTV)/ USB (RTL8761CUV) interface
- Supports USB RTL8771GUV
- Tx Power: 0/4/7.5/14 dBm adjustable (refer to datasheet for details)
- Rx Sensitivity: -102dBm
- Fast AGC control to improve receiving dynamic range
- Max transmit power: 14dBm (refer to specific part number)
- RCP Radio Co-processor
- Thread RCP
- Supports Android/Linux Host
- Supports UART (RTL8761CTV)/ USB (RTL8761CUV) interface
- Supports USB RTL8771GUV
- Tx Power: 0/4/7.5/14 dBm adjustable (refer to datasheet for details)
- Rx Sensitivity: -102dBm
- Fast AGC control to improve receiving dynamic range
- Max transmit power: 14dBm (refer to specific part number)
Part Number Comparison
| Part Number | RTL8771HTV | RTL8771GTV | RTL8771GUV |
|---|---|---|---|
Standard | BLE 5.3/15.4 for Thread | BLE 5.3/15.4 for Thread | BLE 5.3/15.4 for Thread |
RCP interface | UART | UART | USB |
Max Tx Power | 7.5dBm | 14dBm | 14dBm |
Package (mm) | QFN32 5x5 | QFN32 5x5 | QFN32 5x5 |
