Soundbar
Application Overview
Multi-DSP Ready, Mass-Proven

Soundbars have become a popular choice for modern home entertainment systems due to their minimalist design and exceptional audio quality. Realtek provides a Bluetooth solution for soundbars that offers outstanding compatibility and seamless integration with various third-party DSP solutions, giving customers greater flexibility. The solution provides end-to-end technical support covering Bluetooth RF, audio encoding, and DSP interfaces, and has already been implemented in numerous products, passing multi-generation validation. Leveraging this mature solution, customers can fully streamline their product development processes and efficiently bring high-quality soundbar products to market.

System Structure

The soundbar receives audio data from the audio source via Bluetooth and transmits it to an external Digital Signal Processor (DSP) through the I2S interface for further processing. Additionally, the Bluetooth Microcontroller Unit (MCU) communicates with the DSP via a UART interface to ensure precise processing and synchronization of the audio signals.

Application Structure

Application Scenario

The application of soundbars in home multi-task scenarios
Application Scenario
Dual Device Control

In home entertainment scenarios, users often need to switch between multiple tasks on their phones and TVs. This soundbar supports simultaneous dual-device connectivity and enables seamless management of collaborative audio output between the soundbar and TV via a mobile APP. Whether instantly switching from playing a personal phone playlist to TV movie audio, or directly adjusting TV volume and input sources through the APP when the remote is inconvenient to use, all these operations can be effortlessly achieved. This makes multi-device audio management both simple and efficient.

The application of soundbars in home audio-visual systems
Application Scenario
Home Entertainment System

During leisure moments at home, simply connect the soundbar to your multimedia device to enjoy a high-quality audio-visual experience. Compared to the complex setups of traditional audio systems, soundbars offer a simpler and more efficient connection.

Advantages of Solution

Application Advantages
Multi-Device Bluetooth Connectivity

Supports simultaneous connection to two Bluetooth devices, allowing one device to control audio playback on the other, delivering a flexible user experience.

Application Advantages
Excellent Compatibility

Seamlessly compatible with various third-party DSP solutions, ensuring high interoperability.

Application Advantages
Comprehensive Technical Support

Provides comprehensive technical support spanning from Bluetooth RF and audio encoding to DSP interfaces, significantly shortening development cycles and accelerating time to market.

Application Advantages
Extensive Mass Production Experience

The product has been successfully mass-produced in multiple models and validated through generations, demonstrating exceptional stability and reliability.

Recommended Hardware

Choose the SoC that suits your design requirements
RTL8763EFL RTL8763EWM
MCU Real-M300 100MHz Real-M300 100MHz
DSP HiFi mini 200MHz HiFi mini 200MHz
MCM Flash Size 4MB 4MB
SRAM 532KB 532KB
BT Version BT Legacy + LEA + BLE 5.3 BT Legacy + LEA + BLE 5.3
Display N N
Max GPIO number 9 39
SDIO N Y
USB N Y
Package (mm) QFN40, 4X6 QFN76, 6X8
Contact Us
If you are interested in the above products, please contact our REALTEK sales or ask our customer support team for more information.
