RealMCU

In your product, if you need to add BLE function, Realtek's Bee series is definitely your best choice. We offer mutiple BLE SoC solutions with excellent RF performance and low power consumption. Different platforms and interface components also provide flexible choices for various applications. In 2021, more than 200 million chips were applied to their products by our partners. Our best values are excellent RF performance, super-compatible protocol stack, easy-to-do software and tools and the fastest, most detailed services.

Product Comparison

	RTL8762G	RTL8752H	RTL8762E	RTL8762D	RTL8762C
Protocol	BT5.3+2.4G Proprietary Thread/Zigbee 15.4	BT5.2+2.4G Proprietary Thread/Zigbee 15.4	BT5.2+2.4G Proprietary	BT5.1	BT5.0
CPU	CM55@125MHz	CM0+@40MHz	CM0+@40MHz	CM4F@90MHz	CM4F@40MHz
Flash	4Mb/8Mb/16Mb/32Mb/Ext	Ext/4Mb/8Mb	Ext/4Mb/8Mb	Ext/4Mb/8Mb	Ext/2Mb/4Mb
RAM	384KB	120KB	104KB	192KB	160KB
Security	AES128/256 RSA 3072 ECC 512 ECDH ECDSA EDDSA SHA256 TRNG On-The-Fly Trustzone SecureBoot	TRNG AES 128/256 SHA256 SecureBoot	TRNG AES 128/256 SHA256	TRNG Secure Boot AES 128/256 RSA-2048 SHA256	Secure Boot AES 128/256 RSA-2048 SHA256
ADC	8CH 12bit	6CH 12bit	4CH 10bit	8CH 12bit	8CH 12bit
Voice DAC	16bit16KHz	16bit16KHz	16bit16KHz	16bit16KHz	16bit16KHz
PDM	Mono	Mono	Mono	Stereo	Mono
SPI	M x 2 S x 1	SPI x 2	SPI x 2	SPIC x 2 SPI x 2	SPI x 2
I8080	1	1	0	1	1
I2C	4	2	2	2	2
UART	6	3	2	3	3
PWM	8	8	8	8	8
I2S	1	Y	Y	Y	Y
GPIO	(max)60	(max)34	(max)34	(max)38	(max)34
Supply voltage	1.8~3.6	1.8~3.6	1.8~3.6	1.8~3.6	1.8~3.6
Package	32-pin 5x5mm2 QFN 48-pin 6x6mm2 QFN 68-pin 7x7mm2 QFN 47-pin 3.21x3.21mm2 WLCSP	32-pin 5x5mm2 QFN 40-pin 5x5mm2 QFN 48-pin 6x6mm2 QFN	24-pin 3x4mm2 QFN 32-pin 5x5mm2 QFN 40-pin 5x5mm2 QFN 48-pin 6x6mm2 QFN	32-pin 5x5mm2 QFN 40-pin 5x5mm2 QFN 48-pin 6x6mm2 QFN 56-pin 7x7mm2 QFN	40-pin 5x5mm2 QFN 48-pin 6x6mm2 QFN
