RTL8773E Series

Introduction

The RTL8773E is a single-chip Bluetooth SoC audio solution for smart watch applications. The RTL8773E is qualified for Bluetooth 5.4 specifications, and embedded hardware modules include a low-power MCU, a low-power DSP, high-performance audio codec, 2.5D image engine, image decompression unit, power management unit, ADC, ultra-low power RF transceiver, and smart I/O distribution controller.

DESCRIPTION

CHIP

Highlights

highlight
Powerful Graphics Processing Capability

2.5D engine supports rendering, scaling, rotating, deforming, and other processing of graphics.

highlight
Powerful CPU

CPU computing power and MCU memory provide sensor algorithms or external device control capabilities.

highlight
Powerful DSP

DSP computing power provides powerful speech and audio processing capabilities.

highlight
Multi Mode Bluetooth

Includes Bluetooth LE Bluetooth Legacy Audio、LE Audio, Implement product requirements with the latest technology.

Specifications

General Description
  • Bluetooth 5.4
  • BLE Audio
  • Max TX Power +13dBm
  • Receive Sensitivity: -95.8dBm(BR), -95.6dBm (EDR), -100.6dBm (1M BLE), -96.5dBm (2M BLE)
MCU/DSP Platform
  • RM300F, 100MHz
  • HiFi Mini, 200MHz
  • 800kByte SRAM
  • 0/4/8MByte PSRAM
Peripheral Interface
  • 2.5D Graphics Engine
  • Display Controller
  • Image Decompressor
  • AMIC x 2, DMIC x 4
  • Audio DAC x 1
  • Up to 38 GPIOs
  • SPIC x 3
  • SDIO x 1
  • ADC x 4

RTL8773E Series

General Description
  • Bluetooth 5.4
  • BLE Audio
  • Max TX Power +13dBm
  • Receive Sensitivity: -95.8dBm(BR), -95.6dBm (EDR), -100.6dBm (1M BLE), -96.5dBm (2M BLE)
MCU/DSP Platform
  • RM300F, 100MHz
  • HiFi Mini, 200MHz
  • 800kByte SRAM
  • 0/4/8MByte PSRAM
Peripheral Interface
  • 2.5D Graphics Engine
  • Display Controller
  • Image Decompressor
  • AMIC x 2, DMIC x 4
  • Audio DAC x 1
  • Up to 38 GPIOs
  • SPIC x 3
  • SDIO x 1
  • ADC x 4

Part Number Comparison

Part Number
RTL8773EWE
RTL8773EWE―VP
RTL8773EWE―VS

CPU

100MHz

100MHz

100MHz

Flash

External

External

External

MCM PSRAM

N

4MByte

8MByte

A―MIC

2

2

2

DAC

1

1

1

GPIO

38

38

38

SDIO

Y

Y

Y

SPIC

SPIC0, SPIC2

SPIC0, SPIC2

SPIC0, SPIC2

2D/2.5D

Y

Y

Y

Display Resolution

466x466, 16bit, 60fps

466x466, 16bit, 60fps

466x466, 16bit, 60fps

NAND Boot

N

N

Y

Package (mm)

QFN68, 7x7

QFN68, 7x7

QFN68, 7x7

Suggest apps

TopBanner

Smart Watch

TopBanner

Smart Watch

TopBanner

Smart Watch

Applications

Learn about the typical application cases that the RTL8773E series can be used to implement. Of course, there are more applications waiting for you to discover.

appli sce
Smart Watch Solution

Using a single BT SoC as the main controller for the smartwatch, connecting peripherals through interfaces such as SPIC, I2C, SPI, GPIO, I8080, MIC, DAC, etc., and connecting to a mobile phone via Bluetooth, a highly integrated smartwatch solution is achieved.

appli sce
Smart Watch Solution

Using a single BT SoC as the main controller for the smartwatch, connecting peripherals through interfaces such as SPIC, I2C, SPI, GPIO, I8080, MIC, DAC, etc., and connecting to a mobile phone via Bluetooth, a highly integrated smartwatch solution is achieved.

*Specific applications may can only be supported by certain chips
