RTL87x3BFR Series

Introduction

The RTL87x3BFR series chips can be applied to Realtek dual-mode Bluetooth data transfer solution, the Bluetooth chip integrates a complete Bluetooth protocol stack and rich application instructions. The main MCU is connected to the Bluetooth chip through UART, and uses application instructions to configure the basic connection parameters of the Bluetooth chip to expand the Bluetooth transparent transmission interface.



DESCRIPTION

CHIP

Highlights

highlight
Multi-mode

 GATT and SPP profiles inside; Communicate with external MCU by UART.

highlight
High Throughput

Baud rate up to 4Mbps; Default baud rate 115.2kbps; UART I/F (H4 supported);  Hardware flow control supported.

highlight
Completed Development Kits

Full-featured dashboard SDK, with supporting mobile phone APP engineering, which greatly reduces customer's development workload and accelerates the implementation of project.

Specifications

General Description
  • Bluetooth 5.1 core specification
  • BR/EDR/LE-1M/LE-2M
  • LE audio (depends on part number)
  • OTA(Over-the-Air)FW upgrade
  • HS-UART interface for Bluettooth data transmission compliant with H4 specification
RF Performance
  • Max Tx Power 7.5 dBm @EDR 2M (refer to datasheet for details)
  • Max Tx Power 10 dBm @BLE (refer to datasheet for details)
  • RX sensitivity -97.5 dB (1M BLE)
  • RX sensitivity -94.5 dBm (1M BR)
  • RX sensitivity -94 dBm (2M EDR)
  • Fast AGC control to improve receiving dynamic range

RTL87x3BFR Series

General Description
  • Bluetooth 5.1 core specification
  • BR/EDR/LE-1M/LE-2M
  • LE audio (depends on part number)
  • OTA(Over-the-Air)FW upgrade
  • HS-UART interface for Bluettooth data transmission compliant with H4 specification
RF Performance
  • Max Tx Power 7.5 dBm @EDR 2M (refer to datasheet for details)
  • Max Tx Power 10 dBm @BLE (refer to datasheet for details)
  • RX sensitivity -97.5 dB (1M BLE)
  • RX sensitivity -94.5 dBm (1M BR)
  • RX sensitivity -94 dBm (2M EDR)
  • Fast AGC control to improve receiving dynamic range

Part Number Comparison

Part Number
Interface
Profile
Package (mm)
Recommendation Applied

RTL8773BFR

UARTGATT/SPPQFN46, 4.5x6.5
TopBanner

Data Transfer

RTL8753BFR

UARTGATT/SPPQFN40, 4x6
TopBanner

Data Transfer
