RTL8761B Series

Introduction

RTL8761B is a highly integrated Dual Mode Bluetooth5 Transceiver controller chip with UART/USB interface.. It combines BT Protocol Stack (LM, LL,and LE), BT Baseband, modem, and BT RF in a single chip. RTL8761B complies with Bluetooth core specification v5 and supports dual mode (BR/EDR+Low Energy Controllers). It is compatible with previous version including v2.1+ LE. For BR/EDR, it allows multiple active links in either slave mode or master mode. For Low Energy, it supports multiple states and allows multiple active links in slave mode. A BR/EDR link and an LE link can be active at the same time. RTL8761B is suitable for Host device such as PC/TV/OT/Box/Broadband/Automotive applications.

DESCRIPTION

CHIP

Highlights

highlight
Good Compatibility

Widely used in OTT/PC and other devices, with excellent compatibility.

highlight
Multi-mode

BR/EDR/BLE
Master/Slave Mode

highlight
Multi-Application

USB/UART  for PC Dongle/TV/OTT/ Broadband devices

Specifications

General Description
  • Bluetooth 5 BR/EDR/LE Transceiver Controller chip
Interface
  • USB/UART Interface
RF Performance
  • Tx Power up to 10dBm and -94.5dBm 2M EDR receiver sensitivity
  • Support External PA for Tx power

RTL8761B Series

General Description
  • Bluetooth 5 BR/EDR/LE Transceiver Controller chip
Interface
  • USB/UART Interface
RF Performance
  • Tx Power up to 10dBm and -94.5dBm 2M EDR receiver sensitivity
  • Support External PA for Tx power

Part Number Comparison

Part Number
RTL8761BTV
RTL8761BUV
RTL8761BTE
RTL8761BUE

Interface

UART

USB

UART

USB

Package (mm)

QFN32, 4x4

QFN32, 4x4

QFN40, 5x5

QFN40, 5x5

Suggest apps

TopBanner

TV

TopBanner

Box

TopBanner

Broadband

TopBanner

TV

TopBanner

Box

TopBanner

Broadband

TopBanner

PC dongle

TopBanner

Support External PA

TopBanner

Support External PA
